Tracer 50 Q

Tracer 50 Q is an extremely efficient compact up and down wall washer, designed for optical excellence and engineered for complete resilience.Tracer 50 Q features the unonovesette Smart Shield system, complete with an integrated constant current driver, which allows the luminaire to be powered in parallel with a 24Vdc constant voltage power supply.With a deep recess of the in-house designed PCB, Tracer 50 Q offers excellent glare control. Available with a choice of three beam angles (10°, 23°, 43°). Delivered through integration of Total Internal Reflection (TIR) optical technology, which ensure maximum efficacy and complete control of light distribution.

Factory-sealed options include a honeycomb louver.

Read more

Generate a product code

Colour Temp.
Optics
Finishing
Colour Temp.
  • 22 - 2200K
  • 27 - 2700K
  • 30 - 3000K
  • 40 - 4000K
Optics
  • NN - 10° + 10°
  • NM - 10° + 23°
  • NW - 10° + 43°
  • MM - 23° + 23°
  • MW - 23° + 43°
  • WW - 43° + 43°
Finishing
  • 05 - Black anodized
  • 07 - Natural anodized
T5Q.--.-.--
Copy to clipboard
Body
Aluminium 6026
Finishes
Natural anodized / Black anodized
Installation
Surface mounted
Power Supply Cables
35 cm NS20N PCP 2x0,5 mm2
Power Supply
Constant voltage 24Vdc Max
Power Consumption
4 Watt
Lumen Output
2x127 lm
Working Temperature
-20°C +50°C
IP Rating
IP66
Insulation Class
III
Weight
670 g
Code #Tracer 50 Q Input Output IP Sizes Weight
ON/OFF PSU.CX.004 Max 4 110÷240V
50/60 Hz
24Vdc - 20Watt IP20 22mm (height)
110mm (length)
52mm (width)
108g
PSU.CV.005 Max 6 90÷305V
47/63 Hz
24Vdc - 25Watt IP67 32mm (height)
148mm (length)
40mm (width)
360g
PSU.CV.006 Max 14 90÷305V
47/63 Hz
24Vdc - 60Watt IP67 32mm (height)
162mm (length)
43mm (width)
450g
PSU.CV.007 Max 20 90÷305V
47/63 Hz
24Vdc - 90Watt IP67 36mm (height)
161mm (length)
61mm (width)
700g
Dimmable CGE.004 1-10V Max 40 24Vdc
24Vdc IP20 25mm (height)
45mm (length)
58mm (width)
100g
CGE.017- DALI Max 40 24Vdc
24Vdc IP20 25mm (height)
45mm (length)
58mm (width)
100g
CGE.020- DMX Max 40 24Vdc
24Vdc IP20 25mm (height)
45mm (length)
58mm (width)
100g
ACC.084
Honeycomb louver
